WAVEGUIDE

FLANGE TYPE (BRASS)

FIG.NO

DIMENSIONS

TYPE, EIA

U.S.MIL�������������

EIA

INCHES (mms)

WR-90

UG-1736/U

CPR90F

1

2.09*1.59(53.1*40.4)

WR-112

UG-1734/U

CPR112F

1

2.50*1.75(63.5*44.5)

WR-137

UG-1732/U

CPR137F

1

2.69*1.94(68.3*49.3)

WR-159

UG-1730/U

CPR159F

1

3.19*2.44(81.0*62.0)

WR-187

UG-1728/U

CPR187F

1

3.50*2.50(88.9*63.5)

WR-229

UG-1726/U

CPR229F

2

3.88*2.75(98.6*69.9)

WR-284

UG-1724/U

CPR284F

2

4.50*3.00(114*76.2)

WR-340

UG1712/U

CPR340F

2

5.44*3.75(138*93.5)

WR-430

UG-1716/U

CPR430F

2

6.34*4.19(161*106)
